Through Hole Networking Plastic RJ45 Modular Jack W/Y LED 1116173-4
Reference Part Number
1116173-4
Internal Part Number
LPJE101AHNL
Application-LAN
ETHERNET(NON POE)
AutomDX
YES
Package Height (Inches/mm)
0.516/13.10
Package Length (Inches/mm)
0.620/15.75
Package Width (Inches/mm)
0.640/16.26
Configuration TX/RX
T,C
Contact Mating Area Plating
GOLD 6u"/15u"/30u"
Cores Per Port
-
Diodes
No
Latch
Up
LED Option
Green/Yellow LEDS
Number of Ports
1X1
PCB Mount Angle
SIDE ENTRY
PCB Retaining Post
T POST
Pin Type
THT SOLDER
RoHS Compliant
YES-RoHS-5 WITH LEAD IN SOLDER EXEMPTION
Search
YES
Shield EMI Tabs
WITH
Speed
-
Temperature
-40 TO 85°C
Turns Ratio RX
1CT:1
Turns Ratio TX
1CT:1
